Sensata Technologies
Das 1916 gegründete Unternehmen Sensata Technologies ist einer der weltweit führenden Anbieter von Sensor-, Strom-, Steuerungs- und Energiemanagementlösungen. Mit mehr als 21.000 Mitarbeitern und weltweiten Niederlassungen in 13 Ländern unterstützt Sensata Kunden in den Bereichen Automobil, Schwerlastfahrzeuge und Off-Road, Industrie sowie Luft- und Raumfahrt.
Unter den vielen Marken, die Sensata unter seinem Dach vereint, gehören auch Klixon und Airpax, die für ihre robusten Schutzschalter, Präzisionsthermostate und Sensoren bekannt sind.
Klixon, mit seiner langen Geschichte der Innovation, ist ein Synonym für hochwertige Thermoschalter, Thermossicherungen, Thermostate, Präzisionsthermostate sowie thermischen Leistungsschutzschalter und präzise Schutzschaltern für die Luftfahrt. Von der Automobilindustrie über die Luftfahrt bis hin zu kommerziellen und militärischen Anwendungen setzen Hersteller auf Klixon-Produkte, um kritische Funktionen zu überwachen und zu steuern, die Zuverlässigkeit zu erhöhen und eine hohe Sicherheit zu gewährleisten.
Airpax bietet eine umfassende Palette von magnetisch-hydraulischen Schutzschaltern und Thermostaten, die ebenso für ihre Zuverlässigkeit und Genauigkeit bekannt sind und ihren Einsatz primär in industriellen, medizinischen und kommerziellen Anwendungen finden.
Sensata in Zahlen
0
Länder-Niederlassungen
0
Mitarbeiter
0
einzigartige Produkte
0 Mrd.
Umsatz 2023
Produkte
| Serie | Beschreibung | Datenblatt |
|---|---|---|
| Hydraulisch-magnetische Schutzschalter | ||
| 209, 219, 229, 249, 279, 299 | E-Frame Hydraulic-Magnetic Circuit Breakers UL489, UL489A, UL508, UL1077, UL1500, VDE |
|
| AP, UP, AP-MIL | Hydraulic-Magnetic Circuit Breakers UL1077, CSA, FM, MIL-Std-202, MIL-PRF-39019 |
|
| IAG, IUG, IEG, CEG, LEG, CUG, IDG, IMG, CMG, LMG | Hydraulic-Magnetic Circuit Breakers UL489, UL489A, UL1500, UL1077, CSA, CCC, VDE, CE, TÜV (IEC60947-2), MIL-STD-202 |
|
| IAL, CEL, LEL, IDL, IML, IUL, IEL, LML | Hydraulic-Magnetic Circuit Breakers UL489, UL489A, UL1500, UL1077, CSA, CCC, VDE, TÜV (IEC60947-2), MIL-PRF-55629, MIL-STD-202 |
|
| IAR, IUR, IER, CUR, IMR, CER, CMR | „1U, 1RU“ Hydraulic-Magnetic Circuit Breakers UL489A, UL1077, C-UL, VDE, TÜV (IEC60947-2), MIL-STD-202 |
|
| IAX, LUX, LEX | Low-Depth, Hydraulic-Magnetic Circuit Breakers UL489, TÜV (IEC60947-2) |
|
| ICL | DIN Rail-Mount Hydraulic Magnetic Circuit Protectors UL1077, CSA, CCC (GB 14048.2), TÜV (IEC60947-2), CRCC, NFPA130, EN45545-2, BSS7239 |
|
| IELR | DIN Rail-Mount Hydraulic magnetic circuit breaker UL1077, CSA, IEC68-2, TÜV, VDE |
|
| IPA, CPA | Hydraulic magnetic circuit breaker UL1077, CSA, CCC, IEC (601, 950), VDE (0804, 0805), TÜV (EN60934), MIL-PRF-55629, MIL-STD-202 |
|
| JAE, JRE, JLE, JLM, JRM, JTE, JAM | Hydraulic magnetic circuit breaker UL489, UL489A, CSA, CUL/CUR, TÜV, CCC, AS 60947.2-2005 (IEC 60947-2) |
|
| LEGA | Low-Depth, Hydraulic-Magnetic Circuit Breakers UL489, TÜV (IEC60947-2) Ics, CE |
|
| LEJ, LEJA. LUJ | Hydraulic magnetic circuit breaker UL489, CSA, TÜV (IEC60947-2), CE |
|
| ROCB (ICLR, ICLH, ICLM) | Remote Operated Hydraulic magnetic circuit breaker UL1077, CCC (GB14048.2), TÜV (IEC60947-2), CRCC, CSA, IEC 60077-1, EN 50155, NFPA130, EN45545-2, MIL-STD-202, IEC 61373 |
|
| Snapak | Hydraulic magnetic circuit breaker UL489A, UL1077, CSA, SEV, CCC, CE, VDE, TÜV (EN60934), MIL-STD-202 |
|
| Thermische Schutzschalter | ||
| 6766-19 | 35 to 150 Amp Commercial Thermal Circuit Breaker SAE J1625, SAE J1171, SAE J1455, MIL-STD-202 |
|
| 7851, 7854 | 15 to 30 Amp Precision Thermal Circuit Breaker UL, SAE J553, SAE J1171, ABYC E-11, MIL-STD-202 |
|
| 7855 | 175 to 200 Amp Commercial Thermal Circuit Breaker CID A-A-55571/03, CID A-A-55571/08, MIL-STD-202 |
|
| 9115 | 15 to 30 Amp Precision Thermal Circuit Breaker CID A-A-55571/01, CID A-A-55571/02, SAE J553, SAE J1171, UL, CCC, MIL-STD-202 |
|
| C (CA, CM, CDA, CDM) | 2 to 40 Amp Commercial Thermal Circuit Breaker UL, SAE J553, SAE J1171, ABYC E-11, MIL-STD-202 |
|
| F (FDL, FDLA, FDLM, FDLS, FDLT) | 35 to 150 Amp Surface Mount Thermal Circuit Breaker SAE J1455, SAE J1625, SAE J1171, ABYC E-11 |
|
| Small Frame PD (PDA, PDM) | 2 to 40 Amp Precision Thermal Circuit Breaker UL, SAE J553, ABYC E-11, MIL-STD-202 |
|
| Large Frame PD (PDLA, PDLM) | 35 to 150 Amp Precision Thermal Circuit Breaker CID AA55571/04, CID AA55571/07, CCC, MIL-STD-202 |
|
| PS (PSA, PSM) | 2 to 40 Amp Precision Thermal Circuit Breaker UL, CID A-A-55571/05, CID A-A-55571/06, SAE J553, MIL-STD-202 |
|
| PS Neck Mounting (PSM-XX-N) | 2 to 35 Amp Precision Thermal Circuit Breaker UL, SAE J553, MIL-STD-202 |
|
| S (SLA, SDLA, SDLM) | 35 to 150 Amp Commercial Thermal Circuit Breaker UL, SAE J1455, SAE J1625, ABYC E-11, MIL-STD-202 |
|
| Schutzschalter für Luftfahrt & Verteidigung | ||
| 2TC (2TC2, 2TC14, 2TC27, 2TC49) | 1–25 Amp, Single–Phase, Miniature Ambient Compensated Aircraft Circuit Breaker AS58091, MS3320, MS3320L, MS3320V, M5809/1, FAA PMA |
|
| 3TC (3TC2, 3TC14, 3TC27) | 15–35 Amp, Single–Phase, Miniature Ambient Compensated Aircraft Circuit Breaker AS58091, MS14105, MS14105L |
|
| 5TC | 20–50 Amp, Single–Phase, Ambient Compensated Aircraft Circuit Breaker ASNE0732-005, NSA93121 |
|
| 6TC | 2 to 25 Amp, 3–Phase, Miniature, Ambient Compensated Aircraft Circuit Breaker AS58091, MS14154, MS14154L, MS14154V |
|
| 9TC (9TC2) | 1 Amp, 15 to 35 Amp, 3–Phase, Miniature, Ambient Compensated Aircraft Circuit Breaker AS58091, MS14153 |
|
| 15TC (15TC30) | 20 to 50 Amp, Three–Phase, Non–Ambient Compensated Aircraft Circuit Breaker MS90351 |
|
| 20TC | Single-Phase, Switchable On/Off, Rocker-Type Actuator Aircraft Circuit Breaker | |
| 6752-12 | 2½ to 65 Amp, Single–Phase, Ambient Compensated Aircraft Circuit Breaker MIL-DTL-27715, MS24571, MS24571V |
|
| 6752-100 | 50–100 Amp, Single–Phase, 3–Phase, Ambient Compensated Aircraft Circuit Breaker MIL-C-5809, MS25361, MS25361V |
|
| 6752-300 | 2½–90 Amp, 3–Phase, Ambient Compensated Aircraft Circuit Breaker | |
| 3SB (3SB2, 3SB4) | Simulator Aircraft Circuit Breaker, Single–Phase, Low Amp, Quick Trip | |
| 7235, 7236 | Overload Sensing Controls, 7 ½ – 400 Amp | |
| 7270, 7271 | Toggle Switch or Pushbutton, Single–Phase Aircraft Circuit Breaker MIL-C-5809, MS24509A,MS24509B, MS24510A, MS24510B |
|
| 7274 | ½ to 20 Amp, Single–Phase, Non–Compensated, High Performance Aircraft Circuit Breaker MIL-C-5809, MS22073, MS22073V, MS26574, MS26574A, MS26574L |
|
| 7277 | ½ to 20 Amp, Single–Phase, Non–Compensated, General Application Aircraft Circuit Breaker | |
| Serie | Beschreibung | Datenblatt |
|---|---|---|
| Thermoschalter für Geräte/Motoren | ||
| 5AP | Auto DC Motor Protector | |
| 6AP | Auto DC Motor Protector | |
| 2AM, 3AM, 4AM, 8AM | AC on–winding Motor Protectors up to 60 Amp UL547, UL2111, C-UL, CSA, ENEC (EN60730-2-2) |
|
| 7AM | AC on–winding Motor Protectors up to 22 Amp UL547, UL2111, C-UL, CSA, USR (UL2111), CNR, ENEC (EN60730-2-3, EN60730-2-9, EN60730-2-22) |
|
| 17AM | Thermal Protector for Motor / Ballast for Fluorescent and Temperature Sensing Controls UL (E15962, E34618 ), ENEC (2014531.05), CQC |
|
| 3MP | Motor Protector / Thermal Cut-Out C-UL, UL2111, CSA, ENEC (EN60730-2-2, EN60730-2-9) |
|
| 3MP Self Hold | Motor Protector C-UL, UL2111, CSA, ENEC (EN60730-2-2) |
|
| 2MM | Motor Protector / Thermal Cut-Out UL2111, CSA, ENEC (EN60730-2-2, EN60730-2-3, EN60730-2-9) |
|
| YS11 | Small Thermal Motor Protector / Thermal Cut-Out UL (E1596, E34618), ENEC (2014531.1), CQC |
|
| 4TM | Motor Protector Refrigeration Compressors C-UL, UL (E15962), DEKRA ENEC (2014531.15), CQC |
|
| 9700 | Thermal Protector for Motor / Ballast for Fluorescent and Temperature Sensing Controls UL2111, ENEC (EN60730-2-2, EN60730-2-3, EN60730-2-9) CQC |
|
| Phenolic 1P (ME, MG, MR, CE, CG, CR) | Non-Hermetic Phenolic Motor Protector for Single-Phase On-Winding Protection VDE |
|
| Phenolic 3P (MY, MW, CY, CW, BY, BW) | AC OFF-Winding Motor Protection, Non–Hermetic, Three–Phase Phenolics | |
| SB/ESB | Thermal Protection / Locked Rotor Protection / Hermetically sealed BEAB (EN60730-2-1, EN60730-2-2), IEC 730-2-4, UL547, UL873, CSA |
|
| Thermosicherungen für Geräte/Motoren | ||
| MA10 | Thermal Cut-Out ENEC EN60730-2-9, UL873 |
|
| YS10 | Thermal Cut-Out / Small Thermostat Protector UL (E34618), CSA, ENEC (2014531/17), CQC, MITI |
|
| TH10 | Thermal Cut-Out UL (E54813), ENEC (EN60730-2-9, EN60730-2-2, EN60730-1) |
|
| TH11, TH21 | Self Hold Thermal Cut-Outs UL (E54813), ENEC (EN60730-2-9, EN60730-1) |
|
| Thermostate für Industrie | ||
| 6700 | TO-220, Subminiature Bimetal Disc Thermostat cЯUus, VDE, Mil-Std-202 |
|
| 6600 | 8-PIN-DIP, Submimiature Bimetal Disc Thermostat cЯUus, VDE, Mil-Std-202 |
|
| COMBOSENSE 6024 | Temperature Sensor & Thermostat Probe | |
| 5100 | Hermetically Sealed Thermostat Probe UL, CSA, MIL- STD-202 |
|
| 5020 | Hermetically Sealed Thermostat Probe MIL-S-12285/1, MIL- STD-202 |
|
| 5011 | ½ Disc, Hermetically Sealed Thermostat MIL-STD-202 |
|
| 5003 | ½ Bimetal Disc Thermostat | |
| 4100 | Bimetal Disc Thermostat, Brass Probe MIL-STD-202 |
|
| 20425 | High Current Defrost Thermostats, Snap-Action Automatic Reset UL, CSA |
|
| 1NT | Fixed Temperature Thermostats ISO9001: 2000, UL, C-UL, DEKRA ENEC |
|
| 3NT | Fixed Temperature Thermostats ISO9001: 2000, UL, C-UL, DEKRA ENEC |
|
| 20490-20493 | Fixed Temperature Thermostats, Double Pole Automatic / Manual Reset UL, ENEC |
|
| Präzisionsthermostate | ||
| 4344 | Hermetic Sealed Prescision Thermostats Mil-Std-202 |
|
| 4391 | -17,8°C to 232,2°C Hermetically Sealed Prescision Thermostat | |
| 6786 | -29°C bis 117°C Prescision Thermostats, Low Profile, Environmentally Sealed ½“ UL, C-UL |
|
| 3BT, 4BT | -17.8°C to 176.7°C Tiny Stat™ Precision Thermostats MIL-PRF-24236/13, MIL-PRF-24236/19 , NASA S-311-641/06, NASA S-311-641/07, MIL-STD-202 |
|
| 5BT | -53.9°C to 204.4°C SPDT, Welded, Hermetically Sealed ½“ MIL-PRF-24236 /24, MIL-STD-202 |
|
| 7BT, 7BT2 | -1.1°C to 204.4°C High Capacity Thermostat, ½” UL, C-UL, DEKRA ENEC |
|
| M1/11041 (G311P641/05) | S-311-P641/05 Qualified 11041 Series, ½” Hermetic Space Flight Thermostat MIL-PRF-24236/1, NASA S-311-P641/05, MIL-STD-202 |
|
| M1/11041 | ½” Disc Hermetic Thermostats, -53.9°C to 287.8°C, SPST MIL-PRF-24236/1, NASA S-311-P641/05, MIL-STD-202 |
|
| M2 (G311P641/02) | S-311-P641/02 Qualified M2 Series, Narrow Differential, ½” Hermetic Sealed Space Flight Thermostat MIL-PRF-24236/20, NASA S-311-P641/02, MIL-STD-202 |
|
| M2 (M2S-18, M2S-39, M2S-35, M2S-31, 21532) | -17,8°C to 115.6°C, Narrow Differential, ½” Hermetic Sealed Space Flight Thermostat MIL-PRF-24236/20, NASA S-311-P641/02, MIL-STD-202 |
|
| M2 Thermostat Probe (21545, 21546, 21547, 21550) | Thermostat Probe Packages: Narrow Differential Control MIL-PRF-24236/25, MIL-STD-202 |
|
| M1 Thermostat Probe (21542, 21543, 21548, 21549) | Extreme Temperature Protection Probe–Type Thermal Switches MIL-PRF-24236/2, MIL-STD-202 |
|
| ACMP (SKA, MKA, SJE, MJE, BJE) | Single–Phase and Three–Phase Aircraft Motor Protectors MIL-M-7969 |
| Serie | Beschreibung | Datenblatt |
|---|---|---|
| AT, 3AT, 4AT, 10AT | Snap Action Precision Position Switches (Rated 4 Amps @ 28VDC) MIL-PRF-8805 |
|
| 12AT | Taggle Actuated Hermetic Precision Switches IL-PRF-8805 |
|
| 2SE | Solid-State Vane Switch With Airflow Sensing MIL-STD-202 |
|
| 6PS | Hermetic Stainless Steel Pressure Switch MIL-E-5400 |
|
| KX, KX4, KX5 | Sine Switch MIL-PRF-8805 |
|
| Hermetic Interlock Switch | High Performance Hermetic Interlock Switch MIL-S-8805D, MIL-STD-202-204 |
